Microservice Architecture¶

The features of Intel® Edge Controls for Industrial (Intel® ECI or ECI) are compatible with a microservice architecture. A microservice encapsulates a service into a lightweight unit of computation with defined resources and interfaces so that they can be orchestrated. The implementation in Intel® ECI relies on Docker.

Docker is a set of platform-as-a-service (PaaS) products that use OS-level virtualization to deliver software in packages called containers. Containers are isolated from one another and bundle their own software, libraries, and configuration files; they can communicate with each other through well-defined channels. All containers are run by a single operating system kernel and are thus more lightweight than virtual machines.

Docker is used in the ECI image to allow containerization of various applications and services.

For more information, refer to the Docker documentation.

Docker¶

Terminology¶

The following terms are used in this document:

<image>: The name of a container image, which is built with docker build -t <image> and can be instantiated.
<tag>: Particular version of an image, forming its complete name as <image>:<tag>.
<container>: The name of a container instantiated from an image with docker run --name <container> <image>:<tag>.

Install Docker¶

For any system that will use Docker, ensure that Docker (version 19.03.15 or higher) is installed and the user is part of the docker group. For information on installing and configuring Docker, refer to the following:

Install Docker

Manage Docker as a non-root user

Useful Docker Commands¶

Description

Commands
To build a Docker container from a directory containing a Dockerfile
$ docker build . -t <image>:<tag>
To save a Docker image into an archive
$ docker save -o <image>.tar <image>:<tag>
To load a Docker image
$ docker load < <image>.tar
To run a Docker container
$ docker run --name <container> <image>:<tag>
To list the containers that are currently running
$ docker ps
To kill a container
$ docker kill <container>

Build and Deploy Docker Images¶

With this procedure, a Docker <image> is built on a build machine, exported into a tar archive, and then loaded onto the target. The Docker image can then be instantiated on the target as <container>.

Build Docker Image¶

The following section is applicable to:

Navigate to the directory containing the Dockerfile. From a terminal, run the following command, replacing <image> and <tag> with values of your choice:
```
$ docker build -t <image>:<tag> .
```
Note: The “.” at the end of the command is intentional.
Run the following command to save the Docker <image> as a tar archive; replace <image> and <tag> with the values used in the previous step:
```
$ docker save -o <container>.tar <image>:<tag>
```

Deploy Docker Image¶

The following section is applicable to:

Transfer the Docker image tar archive to the target system.
Run the following command to load the <image> from the tar archive; replace <container> with the name of the tar archive:
```
$ docker load < <container>.tar
```
Run the following command to check whether the image has been loaded correctly:
```
$ docker images
```

Optimizations for Docker Containers¶

The following section is applicable to:

There are many possible optimizations that can be performed to improve the determinism of a container. The following script applies a general set of optimizations which are typically applicable to most use cases.

Note

The script below assumes that the pqos tool has been installed. Refer to the following section for more information about the pqos tool and installation instructions: Intel® Resource Director Technology (Intel® RDT)

# Disable Machine Check
echo 0 > /sys/devices/system/machinecheck/machinecheck0/check_interval

# Disable RT runtime limit
echo -1 > /proc/sys/kernel/sched_rt_runtime_us

output=$(cpuid | grep 'cache allocation technology' | grep 'true')
if [[ -z ${output} ]]; then
    echo "This processor does not support Cache Allocation Technology (CAT)."
    echo "Performance will be degraded!"
else
    # Configure cache partitioning
    # Reset allocation
    pqos -R
    # Define the allocation classes for the last-level-class (llc)
    # Class 0 is allocated exclusive access to the first half of the llc
    # Class 1 is allocated exclusive access to the second half of the llc
    pqos -e 'llc:0=0x0f;llc:1=0xf0'
    # Associate core 0 with class 0, and cores 1-3 with class 1
    pqos -a 'llc:0=0;llc:2=1,2,3'
fi

# Change affinity of all interrupts to core 0
for i in `cat /proc/interrupts | grep '^ *[0-9]*[0-9]:' | awk {'print $1'} | sed 's/:$//' `;
do
    # Timer
    if [ "$i" = "0" ]; then
        continue
    fi
    # cascade
    if [ "$i" = "2" ]; then
        continue
    fi
    echo setting $i to affine for core 0
    echo 1 > /proc/irq/$i/smp_affinity
done

# Offload RCU
for i in `pgrep rcu`; do taskset -pc 0 $i > /dev/null ; done

# Start container with Docker Daemon, where <name> and <image> are changed per application
# Assign container to cores 1-3 and add capability to run tasks at highest priority
docker run -d --name <name> --cpuset 1-3 --ulimit rtprio=99 --cap-add=sys_nice <image>

See further Docker Runtime Optimizations.

Microservice Dockerfile Templates for ECI¶

The ECI release provides microservice Dockerfile templates for convenience. The ECI release archive (release-eci_#.#.zip) within the Edge-Controls-for-Industrial directory contains the Dockerfiles.tar.gz archive. This archive contains the files required to build the ECI microservices as containers and their dependencies.

The following section is applicable to:

Prepare Build System for Microservices¶

Do the following to prepare the build system to create the microservice Dockerfile images:

Install Docker if not already done.
Download the ECI release archive, if not done already.
Copy the Dockerfiles.tar.gz archive from the ECI release archive (release-eci_#.#.zip) to the Linux build system. This archive is located in the ECI release archive within the Edge-Controls-for-Industrial directory as follows:
```
└── Edge-Controls-for-Industrial
    ├── Codesys_Example_Applications.zip
    ├── Dockerfiles.tar.gz
    └── eci-release.tar.gz
```
Open a terminal on the Linux build system and change to the directory containing the Dockerfiles.tar.gz archive.
From the terminal, run the following command to extract the Dockerfiles.tar.gz archive:
```
$ tar -xzvf ./Dockerfiles.tar.gz
```

Build Microservice Docker Images¶

Explore the following topics to learn about the various microservice templates that ECI offers:

Section	Description
Microservice: EC Protocol Bridge and Plugins	Dockerfile template for Edge Control Protocol Bridge
Microservice: CODESYS Linux Runtime and CODESYS Edge Gateway	Dockerfile template for CODESYS Linux Runtime

Docker Sanity Checks¶

Sanity Check #1: Docker Daemon¶

The following section is applicable to:

Run the following command:

docker ps

The expected results are as follows:

CONTAINER ID        IMAGE               COMMAND             CREATED             STATUS              PORTS               NAMES

Sanity Check #2: Build TSN Image¶

The following section is applicable to:

Create or modify a file named ~/Dockerfile, and copy the following text into the file:

FROM ubuntu:18.04
RUN apt update
RUN apt -y install build-essential iputils-ping iproute2 git
RUN git clone https://github.com/intel/iotg_tsn_ref_sw.git
RUN cd iotg_tsn_ref_sw && git checkout tags/MR4rt-B-01 && cd sample-app-taprio && make

Save the Dockerfile and run the following commands:

$ cd ~
$ docker build -t tsn:ubuntu .
$ docker image ls

The expected results are as follows:

REPOSITORY          TAG                 IMAGE ID            CREATED             SIZE
tsn                 ubuntu              97d0e4730406        11 days ago         456MB
ubuntu              latest              ccc6e87d482b        4 weeks ago         64.2MB

Sanity Check #3: Bridge Virtual Ethernet to Physical Ethernet¶

The following section is applicable to:

Run the following commands:

$ docker network create -d macvlan --subnet=192.168.0.0/24 -o macvlan_mode=bridge -o parent=${interface_name} bridge_phy
$ docker network ls

Note: ${interface_name} is any physical Ethernet card interface name.

The expected results are as follows:

NETWORK ID          NAME                DRIVER              SCOPE
86b23e5bdc5d        bridge              bridge              local
3a2c6855f291        bridge_phy          macvlan             local
40b8ac2b5880        host                host                local
1cf678554442        none                null                local

Run the following commands:

$ ip link add bridge.docker link ${interface_name} type macvlan mode bridge
$ ip address add 192.168.0.100/24 dev bridge.docker
$ ip link set dev bridge.docker up
$ ip address show dev bridge.docker

The expected results are as follows:

116: bridge.docker@${interface_name}: <BROADCAST,MULTICAST,DYNAMIC,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000
    link/ether 36:73:72:85:b2:1f brd ff:ff:ff:ff:ff:ff
    inet 192.168.0.100/24 brd 192.168.0.255 scope global bridge.docker
       valid_lft forever preferred_lft forever
    inet6 fe80::3473:72ff:fe85:b21f/64 scope link
       valid_lft forever preferred_lft forever

Run the following commands:

$ docker run --net=bridge_phy --ip=192.168.0.101 -it --name tsn tsn:ubuntu
$ ping ${host_ip}

Note: ${host_ip} is any host IP on local network.

The expected results are as follows:

PING ${host_ip} (${host_ip}) 56(84) bytes of data.
bytes from ${host_ip}: icmp_seq=1 ttl=64 time=1.27 ms
bytes from ${host_ip}: icmp_seq=2 ttl=64 time=0.897 ms
bytes from ${host_ip}: icmp_seq=3 ttl=64 time=0.434 ms
bytes from ${host_ip}: icmp_seq=4 ttl=64 time=0.436 ms

Sanity Check #4: Join a Kubernetes (k8s) Cluster¶

The following section is applicable to:

Make sure Docker is configured properly to pull images from external servers. If needed, include the proxy configuration as described in the Control Docker with systemd section.
Collect the following information from the Kubernetes master:
- connection string in the form IP:PORT
- token
- discovery token hash

Run the following command:

$ kubeadm join ``connection string`` --token ``token`` --discovery-token-ca-cert-hash ``discovery token hash``

When the command completes, the node becomes visible to the master. The expected results are as follows:

[preflight] Running pre-flight checks
[WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
[WARNING SystemVerification]: missing optional cgroups: hugetlb
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -oyaml'
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...

This node has joined the cluster:

Certificate signing request was sent to api-server and a response was received.
The Kubelet was informed of the new secure connection details.

Run kubectl get nodes on the control-plane to see this node join the cluster.
