Microservice: CODESYS Linux Runtime and CODESYS Edge Gateway

The following section describes the procedure to integrate a containerized CODESYS SoftPLC. These instructions assume that you have an existing ECI installation and you are familiar with building Docker containers and running the CODESYS Software PLC.

The following section is applicable to:

../../_images/linux1.png

Build CODESYS Containers

Do the following to build Docker images that contain CODESYS components:

  1. If not already completed, prepare the build system.

  2. Open a terminal on the build system and navigate to the extracted Dockerfiles directory. This directory should contain the following:

    $ ls
application-containers  softplc-containers

  3. Navigate to the softplc-containers directory. This directory should contain the following:

    $ ls
build.sh  docker  README.md

  4. Run the build.sh script, located in this directory, to build the CODESYS Docker images:

    /bin/bash build.sh

    Tip

    You can change the version of the CODESYS components installed by editing their Dockerfiles. Edit variable CDS_VERSION in Dockerfile docker/Dockerfile.controlruntime and variable EDGE_VERSION in Dockerfile docker/Dockerfile.gateway. Supported version of CODESYS are (3.5.15.*, 3.5.16.*, 4.5.0.0).

    After the build has completed successfully, Docker images would have been generated and tarballed. Each of them vary:

    Docker Image Archive Name

    Description of Docker Image

    codesys-control.tar

    Contains only the CODESYS Linux runtime

    codesys-edge-gateway.tar

    Contains the CODESYS Edge Gateway

Execute CODESYS Linux Runtime Container

The following section is applicable to:

../../_images/target4.png

  1. Install Docker if not already done.

  2. Ensure that the Docker daemon is active. Run the following command to restart the Docker daemon:

    Warning: All Docker containers that are currently running will also restart.

    $ systemctl restart docker

  3. Verify the status of the Docker daemon:

    $ systemctl status docker

  4. Copy the Docker images, created earlier, to the target system.

  5. Load the copied Docker image:

    $ docker load < codesys-control.tar

  6. Check the Docker images that are present on the target system:

    $ docker images

    The CODESYS images that were loaded should be present in the list. Note down the names and tags of these images.

    Here is a sample output:

    $ docker images
REPOSITORY             TAG                     IMAGE ID       CREATED              SIZE
codesys-control        4.5.0.0                 7d6256f52029   About a minute ago   258MB

  7. Start the container. Note that <container> and <tag> correspond to the values on the target system:

    $ docker run --cap-add=SYS_PTRACE --network host <container>:<tag>

    For example, here is the command to start the codesys-control container:

    $ docker run --cap-add=SYS_PTRACE --network host codesys-control:4.5.0.0

Execute CODESYS Edge Gateway Container

The following section is applicable to:

../../_images/target4.png

  1. Install Docker if not already done.

  2. Ensure that the Docker daemon is active. Restart the Docker daemon:

    Warning: All running Docker containers will also restart.

    $ systemctl restart docker

  3. Verify the status of the Docker daemon:

    $ systemctl status docker

  4. Copy the Docker image, created earlier, to the target system.

  5. Load the copied Docker image:

    $ docker load < codesys-edge-gateway.tar

  6. Check the Docker images that are present on the target system:

    $ docker images

    The CODESYS image loaded earlier should be present in the list. Note down the names and tags of these images.

    Here is a sample output:

    $ docker images
REPOSITORY             TAG                     IMAGE ID       CREATED              SIZE
codesys-edge-gateway   4.5.0.0                 acfa543d8f20   About a minute ago   161MB

  7. This step is optional. To run the CODESYS Edge Gateway in a separate Docker network called codesys, run the following command to create the network:

    $ docker network create codesys

  8. The CODESYS Edge Gateway must be reachable from external host over the port tcp/1217, hence the parameter -p 1217:1217 is necessary. Run the following commands to start the CODESYS Edge Gateway container:

    $ docker run -d --rm \
  --name codesys-edge-gateway \
  --hostname docker-edge-gateway \
  -p 1217:1217 \
  codesys-edge-gateway

    Note: If a Docker network had been created earlier, add the parameter --network codesys to connect the container to this network:

    $ docker run -d --rm \
  --name codesys-edge-gateway \
  --hostname docker-edge-gateway \
  --network codesys \
  -p 1217:1217 \
  codesys-edge-gateway

  9. You can view all active CODESYS Linux runtimes on the Docker network using the CODESYS IDE. Refer to Install CODESYS IDE for installing the CODESYS IDE.

    The following section is applicable to:

    ../../_images/windows3.png

    With the CODESYS IDE, connect to the CODESYS Edge Gateway using the IP address of the target system and standard port 1217. Any CODESYS Linux runtimes active on the same Docker network will be displayed during a network scan.
